75KW/100HP Marine Tunnel Thruster

Marine tunnel thruster is installed transversely in the bow of a vessel. It primarily used for docking, slow speed maneuvering, emergency steering and station keeping at zero or slow forward speed. According to the propeller type, tunnel thrusters are fallen into CPP tunnel thrusters and FPP tunnel thrusters. This one is the FPP type with 75KW/100HP. It is driven by electric motor and approved by certificates of CCS, BV, ABS, DNV, NK, KR, GL, etc. If you are interested in our products, please be free to contact us, we are very glad to serve you.

Features:

1. Propeller type: FPP

2. Propeller diameter: 600mm

3. Max. thrust: 16KN

4. Frequency: 60Hz

5. Certification: ABS, CCS, DNV, NK, BV, KR, GL, etc.

Marine Tunnel Thruster Installation Drawing

More model parameters:

Model	Motor power (KW)	Frequency (Hz)	Input speed (rpm)	A	B	C	D	E	F
MTT50	60/75	50/60	1450/1755	545	525	600	500	345	551
MTT60	100/120	50/60	1450/1755	651	621	800	600	400	623
MTT70	140/170	50/60	1450/1755	751	721	800	700	450	650
MTT80	220/260	50/60	1450/1755	862	822	920	800	500	710
MTT90	220/260	50/60	1450/1755	962	922	920	900	550	800
MTT110	345/400	50/60	1450/1760	1158	1126	1200	1100	650	862
MTT130	450/500	50/60	1450/1760	1360	1328	1265	1300	780	932
MTT150	560/630	50/60	1450/1760	1570	1534	1400	1500	880	1040
MTT165	680/780	50/60	1450/1770	1732	1692	1611	1650	950	1146
MTT180	880/930	50/60	1450/1770	1882	1842	1690	1800	1040	1220
MTT200	1150/1000	50/60	1450/1180	2082	2038	1890	2000	1160	1327
MTT250	1800/1700	50/60	975/880	2620	2560	2280	2500	1460	1780
MTT275	2300/200	50/60	975/880	2890	2810	2335	2750	1635	1911
MTT300	2800/3050	50/60	735/880	3150	3060	2500	3000	1810	2180

Product showing:

75KW/100HP Tunnel Thruster



Azimuth Thruster with Tube

Azimuth thruster with tube is a kind of Z-type propulsion equipment combined with ducted propeller and steering gear function. The part under water can steer by 360 degree free rotating forming all-directional propulsive force. The device combines the highly efficiency of tube propellers and flexibility of azimuth thruster. It is mainly used for various engineering ships with high flexibility or with dynamic positioning demand, such as harbor tugs, undersea cabling working ships, floating crane barges, marine platform and platform supply ships etc. The power range of the products is from 60HP to 3500HP.

Specification:

Model	Power Rating (HP)	Speed Rating (r/min)	Ratio	Dia of propeller (mm)	Matching Diesel Engine	Weight (kg)
HSRP-W300	300	750	2.58	1100	6160	2300
HSRP-W400	400	1800	2.17	1150	NTA855-M350	2500
HSRP-W600	600	1800	3.34	1280	KTA19-M600	4200
HSRP-W1000	1000	1000	2.66	1600	XCW6200ZC-7	6700
HSRP-W1200	1200	1800	3.05	1750	KTA38-M1200	7000
HSRP-W1400	1400	1800	3.24	1850	KTA38-M2	8000
HSRP-W1600	1600	1000	3.23	2000	CW12V200ZC	14500
HSRP-W1800	1800	1000	2.51	2100	XCW12V200ZC	18000
HSRP-W2000	2000	750	2.54	2200	6250	21000
HSRP-W2400	2400	825	2.997	2480	LC8250ZLC-2	23000
HSRP-W2600	2600	1000	3.12	2500	8250	23500
HSRP-W3000	3000	775	3.27	2600	9L28/32	26000
HSRP-W3200	3200	800	3.25	2700	7L27/38	27500

Product showing:



Azimuth Thruster with Tube



Product Description

The single arm electric slewing davit consists of a davit arm,column and electric rescue boat winch.It is mainly used for lifting and lowering varieties of rafts.The davit with electric lifting and electric rotary mechanism has the function of making the davit slew from left to right or from right to left.It has two types,21KN and 25KN.

Technical Parameter

S.W.L(KN)	Hoisting load(KN)	Hoisting speed(m\min)	Lowering speed with full load(m\min)	Capacity of drum(m)	Dia. Of steel(mm)	Slewing radius(m)	Incline limit
21	2	≥18	45~55	45	16	3.85	list≤20° trim≤10°
25					18	3.85
